HMS 12 B2-LD-W
300 (12) mm (in.)Ā |Ā 191 (7.52) mm (in.)Ā |Ā 2Ī© infinite baffle led subwooferĀ |Ā 1000 WĀ |Ā 2 OhmĀ |Ā Single Voice Coil
The classi grille, features built-in LEDs. The motor and suspension design is optimized for high-power, infinite-baffle operation featuring long linear excursion capability for tremendous output with low distortion.Ā Hertz Marine subwoofers not only add tons of bass output to your system but also relieve the main speakers from the hard work of reproducing the lowest frequency range, thus maximizing overall system performance for unlimited sound pressure and emotion!
SizeĀ mm (in.) | 300 (12) |
Power Handling – ContinuousĀ W | 500 |
Power Handling – PeakĀ W | 1000 |
ImpedanceĀ Ohm | 2 |
DepthĀ mm (in.) | 191 (7.52) |
Voice Coil Type | single |
No Filter Component | 2Ī© INFINITE BAFFLE LED SUBWOOFER |
Voice Coil Ć | 65.5 (2.6) |
Magnet size D x d x hĀ mm (in.) | 156 x 80 x 40 (6.14 x 3.15 x 1.57) |
Weight of one componentĀ kg (lb.) | 7,6 (16.8) |
Magnet | High density flux ferrite |
Cone | Polypropylene with UV inhibitors |
DĀ mm | 300 |
XmaxĀ mm | 19 |
ReĀ Ohm | 1.8 |
FsĀ Hz | 30 |
LeĀ mH | 0.41 |
VasĀ I | 95.4 |
MmsĀ g | 114 |
CmsĀ mm/N | 0.225 |
BLĀ T*m | 8 |
Qts | 1 |
Qes | 1.1 |
Qms | 11.1 |
SplĀ dB | 89.5 |
